SS's Xenolithic Gratification Cuboid Worklog

[Noah]

Re: SS's PGC Worklog

The GodDang ShockSlayer does damned good work



[nuke]

Re: SS's PGC Worklog

This makes me want to commission Ashen again.

PS: Noah, wolborg proly still has censoring on, so he can't see the goddamned SS in real.



[Noah]

Re: SS's PGC Worklog

Ah.



[wolborg]

Re: SS's PGC Worklog

yeah i have it on but i wrote dang but i saw on the quote it came up damned that is peculiar



[ShockSlayer]

Re: SS's PGC Worklog

So, if you are an avid ShockSlayer fan who reads all my posts, you'd notice that I posted some pics of some wired up regulators here, and some of a wired up audio amp here.

Well, what do you think I did all that for?

All the regs don't go higher than the fan, so it's all good. Ran the power wires to them, especially proud of the 5v and 3.3v regs, the are positioned so perfectly that the 5v b-hop's GND and Input via one short wire and a solder bridge, just because of how close together they are.

Things to note from the second pic:
- You can see the trimmer mentioned in the amp topic
- My knee is in this pic.
- Oh? That's my ingenious power cable for both the Wii and the GC, the brick is a Wii's, more amps = win.
- You can see my soldering iron's tip, and how it's basically rounded. Gonna RCP with it tomorrow.

SS



[nuke]

Re: SS's PGC Worklog

Damned sexy. Now epoxy/hotglue all that awesome flax together to the back and turn the mobo over. .



[ShockSlayer]

Re: SS's PGC Worklog

I'm just gonna solder and super glue everything, save a ton of space.

SS



[nuke]

Re: SS's PGC Worklog

wat.



[ShockSlayer]

Re: SS's PGC Worklog

Tried powering this off of 4 AA's for lulz, no dice. I might try again when I can disconnect the audio amp and the 5v reg, just to see if I can get the GC to boot.

EDIT: Got a new name, this is now the Xenolithic Gratification Cuboid. You can call it XGC if you want to.

SS



[ShockSlayer]

Episode 10:

http://www.youtube.com/watch?v=Ifwb8nAGAeg



[nuke]

FURST COMMENT VIEWER,ETC!
xD jkjkjk
Edit:Hmm, y u no 2 speakers?



[Tchay]

So lately I've been dremeling down my soldering tips to resharpen them

It actually works! I do that right before DD and memory card soldering. Also had to do it when I wired up the component cable chip.



[SonyQrio]

I take my tips out to the grind wheel and sharpen 'em to a point.



[ShockSlayer]

Yeah, I do that, there comes a point when you can't sharpen them anymore.

?

?

._.



[Mako321]

I take my tips out to the grind wheel and sharpen 'em to a point.

I take my tips

tips

tips




tips

Multiple tips?
I'm quite jealous.



[SonyQrio]



[ShockSlayer]

What



[S5114]

Sexual innuendoes, ponies, and bad puns... At least there's a portable somewhere down the road...



[ShockSlayer]

Hmm, y u no 2 speakers?

That'd be boring and dull, stereo is too mainstream. Mono ftw. /afropalmer

Speaking of Palmer;

Sexual innuendoes, ponies, and bad puns... At least there's a portable somewhere down the road...

Sega please, the godDang ShockSlayer is not known for "pics...tomorrow" he is know for "Progress Today!"

So yeah:

"What is that" you say?

Aha! Some sort of low-profile tact switch! Using these for controls, perfect for my plans.

That one is currently in my digestive system. I ate it. I have 100. It will not be missed.

SS



[S5114]

HOLY *Can'tSayThisOnTV*!!! Those things are small!!! How do they feel? Are they like the rubber tact switches?
